Explain:
It is mainly used for raw material handling or grading in flour milling, feed, rice milling, chemical engineering, food, oil expression and other industries. Many kinds of grains such as wheat, corn, rice, oil-bearing crops can be cleaned by replacing screen pieces with different screen apertures.
Characteristics:
1.Its structure is simple, which can provide convenience for operation and maintenance.
2.It can operate steadily, with low noise;
3.It can achieve high output and low energy consumption;
4.It is featured with satisfactory sealing effect, and it can be equipped with different winnowing devices; besides, no flying dust is found
Technical parameters
|
Spec. & model |
Output (wheat t/h) |
Air suction amount （m³/min） |
Power (kw) |
Size of screen surface (L × W mm) |
Mass (kg) |
Boundary dimension (L × W × H) |
|
TQLX150×250 |
30-60 |
115 |
3 |
1500×2500 |
2300 |
3025×2221×2293 |
|
TQLX150×300 |
35-70 |
125 |
3 |
1500×3000 |
2500 |
3525×2221×2293 |
|
TQLX180×250 |
40-75 |
135 |
4 |
1800×2500 |
2600 |
3025×2521×2293 |
|
TQLX180×300 |
45-80 |
150 |
4 |
1800×3000 |
2800 |
3525×2521×1193 |
|
TQLX200×250 |
50-90 |
160 |
4 |
2000×2500 |
3000 |
3025×2721×2293 |
|
TQLX200×300 |
55-100 |
170 |
4 |
2000×3000 |
3200 |
3525×2737×2293 |
|
TQLX200×360 |
60-120 |
180 |
5.5 |
2000×3600 |
3700 |
4125×2737×2293 |
